Equipment configuration:
Equipment processing width: 450mm, 800mm, 1000mm, 1350mm, 1600mm
Equipment processing thickness: 0.5-80mm
Conveyor feeding speed: 0.5-6m/min (variable frequency adjustable)
Optional feeding methods:
1. Strong permanent magnet adsorption conveying feeding (suitable for carbon steel workpieces. Workpiece size>30mmx30mm)
2. Vacuum negative pressure adsorption conveying feeding (suitable for stainless steel plates, copper plates, aluminum plates, etc. that are not magnetically adsorbed. Workpiece size>50mmx50mm) Four column synchronous lifting and lowering, roller brush station independent lifting, lifting servo control, accuracy 0.01mm. The CNC PLC touch screen of the whole machine adjusts the processing parameters. Equipped with wet vacuum cleaners or industrial pulse vacuum cleaners to process grinding dust and achieve environmentally friendly production.
